If you’re buying a Ranger to pull something — a boat, a camper, a utility trailer, a snowmobile sled — this guide is where to start. The 2026 Ranger has a Class IV trailer hitch receiver available through the Trailer Tow Package, multiple towing package configurations depending on how much control and capability you need, and a lineup of three engines that affect what the truck can pull. There’s also important context on what the OEM source confirms and what it doesn’t — because getting towing specs right matters more than getting content published fast.

What is the 2026 Ford Ranger’s towing capacity?

Towing capacity figures for the 2026 Ford Ranger are listed as TBD in the official 2026 order guide. This is not unusual for a model year guide published early in the cycle — Ford typically releases confirmed towing and payload figures once EPA certification and final engineering validation are complete.

Important: We do not publish unconfirmed towing figures. The 2026 Ranger order guide lists towing and payload as TBD across all engine and drivetrain configurations. Publishing figures from prior model years or third-party estimates as 2026 specs would be inaccurate. We will update this page when Ford releases official 2026 towing capacity figures. Contact Jay Malone Ford at (320) 587-4748 for the most current information.

What is confirmed from the OEM source: the Trailer Tow Package on the 2026 Ranger includes a Class IV trailer hitch receiver — one of the heavier-duty hitch classes available in the mid-size truck segment. The towing package content, configuration options, and availability by trim are all fully confirmed and covered in detail below.

What is the 2026 Ford Ranger’s payload capacity?

Payload figures are also listed as TBD across all configurations in the 2026 order guide. The payload selector chart in the OEM document shows TBD for every engine and drivetrain combination — 4x2 2.3L, 4x4 2.3L, 4x4 2.7L, and 4x4 3.0L (Raptor). This page will be updated when official figures are confirmed by Ford.

What matters in the meantime: every Ranger configuration uses a fully boxed steel frame, and the truck is designed around genuine mid-size truck capability. If payload is a critical factor in your purchase decision — for example, if you’re hauling materials in the box regularly — contact us and we’ll give you the most current information available from Ford.

What does the 2026 Ranger Trailer Tow Package include?

The Trailer Tow Package (option code 53R) is the foundational towing equipment package on the 2026 Ranger. It is available on XL, XLT, and Lariat, and is standard on the Raptor. Without this package on XL, XLT, and Lariat, the truck does not include a trailer hitch receiver.

Trailer Tow Package (53R) includes:

• Class IV Trailer Hitch Receiver — the heaviest-duty hitch class in the Ranger lineup
• 4-pin/7-pin wiring harness — supports trailers with electric brakes and multiple light circuits

Note: The XL base configuration includes 4-pin wiring and ball mounting provisions in the rear bumper as standard equipment — but it does not include the trailer hitch receiver itself. The Trailer Tow Package adds the Class IV receiver and the 7-pin harness.

The Trailer Tow Package is also included within the Advanced Towing Package (67P) and Advanced Towing Package Plus Technology Package (67G) — you do not need to add it separately when ordering either of those bundles.

What is the Advanced Towing Package?

The Advanced Towing Package (option code 67P) is available on XLT and Lariat and bundles the Trailer Tow Package with two additional active towing features.

Advanced Towing Package (67P) includes:

• Trailer Tow Package (53R) — Class IV hitch receiver and 4-pin/7-pin wiring
• Trailer Brake Controller — integrated system that manages electric trailer brakes; allows the driver to set braking gain and provides manual override capability
• Pro Trailer Backup Assist™ — allows the driver to steer a trailer in reverse using a rotary knob on the dashboard while the truck handles the counter-steering automatically

The Advanced Towing Package is the right choice for buyers who tow regularly, tow trailers with electric brakes, or who want help with backing a trailer in tight spots. For most central Minnesota buyers towing a boat to one of the area lakes or backing a camper into a site, this package delivers genuine real-world value.

What does the Advanced Towing Package Plus Technology Package add?

The Advanced Towing Package Plus Technology Package (option code 67G) is the most comprehensive towing configuration available on the 2026 Ranger. It is available on XLT and Lariat, and it combines full towing hardware with the complete Technology Package in a single bundle.

Advanced Towing Package Plus Technology Package (67G) includes everything in 67P, plus:

• Rear Parking Sensors with Trailer Guidance — the rear sensors remain active while a trailer is connected and provide guidance for trailer alignment
• 360-Degree Camera — provides a bird’s-eye view of the truck and surroundings, useful for tight maneuvering with a trailer attached
• Adaptive Cruise Control with Speed Sign Recognition — maintains set following distance and adjusts for posted speed limits
• Front Parking Sensors — proximity detection for tight spaces

Important compatibility notes confirmed from the OEM source:

• 67G is not available with the standalone Technology Package (67Y) — they are mutually exclusive on XLT
• 67G is not available with the standalone Advanced Towing Package (67P) — they are mutually exclusive
• On Lariat, the Technology Package content is already standard — the 67G adds the towing hardware to what Lariat already has

Does the 2026 Ranger have a Trailer Brake Controller?

Yes — but it requires a package. The Integrated Trailer Brake Controller is included in the Advanced Towing Package (67P) and Advanced Towing Package Plus Technology Package (67G) on XLT and Lariat. On XL, the Integrated Trailer Brake Controller is available as a standalone option (option code 66D) when the Trailer Tow Package (53R) is ordered.

The Raptor includes the Trailer Brake Controller as part of its standard Advanced Tow Package.

If you’re towing a trailer with electric brakes — most boat trailers, campers, and utility trailers above a certain weight threshold — a trailer brake controller is required by law in Minnesota when towing trailers over 3,000 lbs. The integrated system in the Ranger communicates directly with the truck’s braking system for better coordination than an aftermarket add-on.

What is Pro Trailer Backup Assist™ and how does it work?

Pro Trailer Backup Assist™ is an active driver assistance system that takes the counter-steering challenge out of backing a trailer. Instead of turning the steering wheel opposite to the direction you want the trailer to go, you use a rotary knob on the dashboard — turn it left to move the trailer left, right to move it right. The truck handles the necessary steering inputs automatically.

It’s available through the Advanced Towing Package (67P) and Advanced Towing Package Plus Technology Package (67G) on XLT and Lariat. It is standard on the Raptor as part of its standard Advanced Tow Package. It is not available on the XL in any configuration.

For buyers who tow a boat or camper and occasionally need to back into a slip, a campsite, or a tight storage space, Pro Trailer Backup Assist™ is one of the most genuinely useful real-world features available on the Ranger.

Towing package availability by trim — 2026 Ford Ranger

Package / Feature	XL	XLT	Lariat	Raptor
4-pin wiring + ball mount provisions	✓ Std	✓ Std	✓ Std	✓ Std
Trailer Tow Package (53R) — Class IV hitch + 7-pin	Optional	Optional	Optional	✓ Std
Integrated Trailer Brake Controller	Optional (req. 53R)	w/ 67P or 67G	w/ 67G	✓ Std
Pro Trailer Backup Assist™	—	w/ 67P or 67G	w/ 67G	✓ Std
Rear Parking Sensors w/ Trailer Guidance	—	w/ 67G only	w/ 67G only	✓ Std
360-Degree Camera	—	w/ 67G or 67Y	✓ Std	✓ Std
Adaptive Cruise Control	—	w/ 67G or 67Y	✓ Std	✓ Std

Does engine choice affect towing on the 2026 Ranger?

Engine choice matters for towing — but because the 2026 order guide lists towing figures as TBD across all configurations, we cannot publish confirmed capacity differences between the 2.3L, 2.7L, and 3.0L engines at this time. What the OEM source does confirm:

• The 2.3L EcoBoost® is available on XL, XLT, and Lariat in 4x2 or 4x4
• The 2.7L EcoBoost® is available on XLT and Lariat with 4x4 only — not available in 4x2
• The 3.0L EcoBoost® V6 is exclusive to the Raptor and comes with 4x4 and a 4.27 rear axle ratio optimized for off-road low-speed torque

For buyers who specifically need the highest towing capacity the Ranger offers and the 2.7L is under consideration, contact Jay Malone Ford when official figures are released. We’ll have the confirmed numbers and can help you determine whether the larger engine changes the equation for your specific towing needs.

Towing in central Minnesota — what Ranger buyers should know

For buyers in Hutchinson, Willmar, Litchfield, Glencoe, and the surrounding area, towing isn’t a hypothetical question — it’s a regular part of truck ownership. Here are the practical towing considerations specific to central Minnesota buyers:

Boat and recreational trailer towing: Kandiyohi, McLeod, Meeker, and surrounding counties have hundreds of lakes. Walleye opener, summer pontoon season, and fall fishing trips mean a lot of Ranger owners in this area will be backing into boat ramps on a regular basis. If that’s you — the Advanced Towing Package with Pro Trailer Backup Assist™ is worth serious consideration. Backing a boat trailer into a crowded ramp on a busy opener morning is the exact use case it was designed for.

Snowmobile and ATV trailers: Closed trailers for snowmobile sleds and open trailers for ATVs are common in this area from October through April. Most of these trailers have electric brakes above a certain weight. The Trailer Brake Controller in the Advanced Towing Package is the right solution — and under Minnesota law, a trailer brake controller is required when towing a trailer weighing more than 3,000 lbs.

Farm and utility trailers: Livestock trailers, hay wagons, and equipment trailers used on farms and acreages in McLeod County and surrounding areas typically have electric brakes and require a Class IV hitch. The Trailer Tow Package covers the hitch; the Advanced Towing Package adds the brake controller.

Engine Block Heater (41H): If you tow in winter — and in central Minnesota, that means pulling a sled trailer to a groomed trail system or hauling equipment in subzero conditions — adding the Engine Block Heater at purchase is worth it. A warm engine pulls harder and more reliably in extreme cold than a cold-start engine under load.

For the full Ranger spec and trim breakdown, visit our 2026 Ford Ranger overview page.

Frequently Asked Questions

What is the towing capacity of the 2026 Ford Ranger?

Towing capacity figures for the 2026 Ranger are listed as TBD in the official Ford order guide and have not been confirmed at time of publication. This page will be updated when official EPA-certified figures are released. Contact Jay Malone Ford at (320) 587-4748 for the most current information.

Does the 2026 Ford Ranger come with a trailer hitch?

Not automatically. The XL, XLT, and Lariat require the Trailer Tow Package (53R) to add the Class IV trailer hitch receiver. The XL base configuration includes 4-pin wiring and ball mount provisions in the bumper but not the receiver itself. The Trailer Tow Package is standard on the Raptor.

What is the difference between the Ranger’s towing packages?

Three levels: Trailer Tow Package (53R) gives you the Class IV hitch and 7-pin wiring. Advanced Towing Package (67P) adds Trailer Brake Controller and Pro Trailer Backup Assist™. Advanced Towing Package Plus Technology Package (67G) adds all of that plus Rear Parking Sensors with Trailer Guidance, 360-Degree Camera, Adaptive Cruise Control, and Front Parking Sensors. 67P and 67G are only available on XLT and Lariat.

Does the 2026 Ranger have Pro Trailer Backup Assist?

Yes — on XLT and Lariat through the Advanced Towing Package (67P) or Advanced Towing Package Plus Technology Package (67G), and standard on the Raptor. It is not available on the XL in any configuration.

Do I need a trailer brake controller with my Ranger?

In Minnesota, a trailer brake controller is required by law when towing a trailer that weighs more than 3,000 lbs. If your trailer has electric brakes — which most boats, campers, and enclosed utility trailers above that threshold do — you need one. The Ranger’s integrated Trailer Brake Controller is available through the Advanced Towing Package on XLT and Lariat, and as a standalone option on XL (requires Trailer Tow Package 53R). It is standard on the Raptor.

Can the 2026 Ranger tow a boat in Minnesota?

Yes. The Ranger is a capable boat tower for the typical lake boats used in central Minnesota — aluminum fishing boats, smaller pontoons, and bass boats. The Trailer Tow Package adds the Class IV hitch and 7-pin wiring. For regular lake use with backing into boat ramps, the Advanced Towing Package with Pro Trailer Backup Assist™ is a worthwhile addition. Official 2026 towing figures are TBD — contact Jay Malone Ford for the latest numbers when confirmed.

Towing is one of the most common reasons buyers in Hutchinson and across central Minnesota choose a mid-size truck over a smaller pickup or SUV. The Ranger’s towing package options are well-configured for that use — and the Advanced Towing Package with Pro Trailer Backup Assist™ is one of the more genuinely useful technology investments available on the truck. If you want to talk through which configuration makes sense for what you haul, stop in at Jay Malone Ford at 1165 Highway 7 West, give us a call at (320) 587-4748, or browse our current Ranger inventory online. We’ll give you a straight answer.

For the full Ranger trim and spec breakdown, visit our 2026 Ford Ranger overview page.
